Исполнительный механизм	Классификация	Стандартный	Высокочуствительный	Сверх высокочуствительный	Мощный	Микронагрузки
	Contact gap	G (0.5 mm)	Н (0.25 mm)	Н2 (0.20 mm)	Е (1.8 mm)	Н (0.25 mm)
	Terminal	Модель	Модель	Модель	Модель	Модель
Pin plunger		Z-15G	Z-15H	Z-15H2	Z-15E	Z-01H
Pin plunger		Z-15G-B	Z-15H-B	Z-15H2-B	Z-15E-B	Z-01H-B
Slim spring plunger		Z-15GS	Z-15HS	---	---	Z-01HS
Slim spring plunger		Z-15GS-B	Z-15HS-B	---	---	Z-01HS-B
Short spring plunger		Z-15GD	Z-15HD	---	Z-15ED	Z-01HD
Short spring plunger		Z-15GD-B	Z-15HD-B	---	Z-15ED-B	Z-01HD-B
Panel mount plunger	Low OP	Z-15GQ3	---	---	---	---
	Low OP	Z-15GQ3-B	---		---	---
	Medium OP	Z-15GQ	Z-15HQ		Z-15EQ	Z-01HQ
	Medium OP	Z-15GQ-B	Z-15HQ-B		Z-15EQ-B	Z-01HQ-B
	High OP	Z-15GQ8	---		---	---
	High OP	Z-15GQ8-B	---		---	---
Panel mount roller plunger		Z-15GQ22	Z-15HQ22	---	Z-15EQ22	---
Panel mount roller plunger		Z-15GQ22-B	Z-15HQ22-B	---	Z-15EQ22-B	---
Panel mount cross roller plunger		Z-15GQ21	Z-15HQ21	---	Z-15EQ21	---
Panel mount cross roller plunger		Z-15GQ21-B	Z-15HQ21-B	---	Z-15EQ21-B	---
Leaf spring		Z-15GL	---	---	---	---
Leaf spring		Z-15GL-B	---	---	---	---
Roller leaf spring		Z-15GL2	---	---	---	---
Roller leaf spring		Z-15GL2-B	---	---	---	---
Short hinge lever		Z-15GW21	---	---	---	---
Short hinge lever		Z-15GW21-B	---	---	---	---
Hinge lever	Low OP	Z-15GW	Z-15HW	---	---	---
	Low OP	Z-15GW-B	Z-15HW-B
	Medium OP	Z-15GW3	---
	Medium OP	Z-15GW3-B
	High OP	Z-15GW32
	High OP	Z-15GW32-B
Low-force hinge lever		Z-15GW4	Z-15HW24	---	---	---
Low-force hinge lever		Z-15GW4-B	Z-15HW24-B	---	---	---
Low-force wire hinge lever	LowOP	---	Z-15HW78	---	---	---
	LowOP		Z-15HW78-B
	HighOP		Z-15HW52
	HighOP		Z-15HW52-B
Short hinge roller lever		Z-15GW22	Z-15HW22	---	Z-15EW22	Z-01HW22
Short hinge roller lever		Z-15GW22-B	Z-15HW22-B	---	Z-15EW22-B	Z-01HW22-B
Short hinge cross roller lever		Z-15GW49	---	---	---	---
Short hinge cross roller lever		Z-15GW49-B	---	---	---	---
Hinge rolle rlever	Standard	Z-15GW2	Z-15HW2	---	---	---
	Standard	Z-15GW2-B	Z-15HW2-B		---	---
	Largeroller	Z-15GW25	---		---	---
	Largeroller	Z-15GW25-B	---		---	---
Hinge cross roller lever		Z-15GW54	---	---	---	---
Hinge cross roller lever		Z-15GW54-B	---	---	---	---
Unidirectional short hinge roller lever	Parallel	Z-15GW2277	---	---	---	---
Unidirectional short hinge roller lever	Parallel	Z-15GW2277-B	---	---	---	---
Reverse hinge lever		Z-15GM	---	---	---	---
Reverse hinge lever		Z-15GM-B	---	---	---	---
Reverse short hinge roller lever		Z-15GM22	---	---	---	---
Reverse short hinge roller lever		Z-15GM22-B	---	---	---	---
Reverse hinge roller lever		Z-15GM2	---	----	---	---
Reverse hinge roller lever		Z-15GM2-B	---	----	---	---

Минимальное количество в упаковке

Классификация	Стандартный	Высокочувствительный	Минимальный заказ (шт.)
Short spring plunger	Z-15GD-B	—	10
Panel mount plunger	Z-15GQ; Z-15GQ-B; Z-15GQ8-B	---
Panel mount roller plunger	Z-15GQ22; Z-15GQ22-B	---
Panel mount cross roller plunger	Z-15GQ21-B	—
Short hinge lever	Z-15GW21-B	—
Hinge lever	Z-15GWZ-15GW-B	---
Low-force hinge lever	Z-15GW4-B	Z-15HW24-B
Low-force hinge wire lever	—	Z-15HW78-B
Short hinge roller lever	Z-15GW22; Z-15GW22-B	---
Hinge roller lever	Z-15GW2Z-15GW2-B	---
Reverse short hinge roller lever	Z-15GM22-B	—
Reverse hinge roller lever	Z-15GM2-B	—

Характеристики

Rated voltage	Non-inductive load				Inductive load
	Resistive load		Lamp load		Inductive load		Motor load
	NC	NO	NC	NO	NC	NO	NC	NO
125 VAC	15 A		3 A	1.5 A	15 A		5 A	2.5 A
250 VAC	15 A		2.5 A	1.25 A	15 A		3 A	1.5 A
8 VDC	15 A		3 A	1.5 A	15 A		5 A	2.5 A
14 VDC	15 A		3 A	1.5 A	10 A		5 A	2.5 A
30 VDC	6 A		3 A	1.5 A	5 A		5 A	2.5 A
125 VDC	0.5 A		0.5 A	0.5 A	0.05 A		0.05 A	0.05 A

Концевые выключатели OMRON: каталог и характеристики

«Концевые выключатели» (OMRON) — 2 727 позиций в каталоге. Основные типы: D4N, WL, Z, D4C, D4B, WL-N, D4A, D4ER-N, D4CC, D4F, D4E, ZC.

Цены — от 1 541 до 19 561 ₽.
